ICON 2018-2023 Jeep Wrangler JL, 2.5" Lift, Rear, V.S. 2.5 Aluminum Series Shock Absorbers, Piggyback Reservoir w/ CDEV, Pair at Sexton Offroad in Salt Lake City & Park City, Utah

ICON Vehicle Specific (V.S.) 2.5 Aluminum Series shocks with CDEV are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. Like all ICON'S Shock Absorbers, V.S. 2.5 Aluminum Series shocks with CDEV are 100% rebuildable and 100% revalveable.

Compression Damping Electronic Valve (CDEV) is an electronically controlled valve that meters the flow of oil to regulate the amount of damping force that is created by the shock when compressed. This infinitely variable valve can react in less than 40ms and has the ability to make extremely precise adjustments for varying terrain. CDEV’s hydraulic circuits are also custom tailored per application to create the highest resolution and dynamic range allowable for each specific vehicle. Powered by ICON Intelligent Control and proprietary ICON mobile app, the system uses information from the onboard G-force sensor and Gyroscope to perform calculations based on algorithms and user-defined settings to predict terrain and adjust shock settings via the CDEV accordingly.

Features | Specification:

• ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC)
• ICON’s internal “Bump Zone" increases damping by 20% to provide more control as the shock approaches full compression
• One-piece, hard anodized, impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
• Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
• Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
• Nitrogen charged monotube design with piggyback reservoir
• One-piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
• 7/8" diameter induction hardened, chrome plated shock shaft
• PTFE lined spherical bearings and application specific mounting hardware
• 6061 aircraft grade aluminum CNC machined components
• 100% Rebuildable
• 100% Revalveable

Note(s):

• Also requires installation of IIC kit (Part # 23502) and CDEV front shocks (Part # 27821EP)
• Only fits models equipped with 3.6L "Pentastar" V6 gasoline engine.
• An iOS operated device is required to run ICON Intelligent Control App

Upgrade your 4x4 with quality parts and accessories from Sexton Offroad. Visit us for installation at our Salt Lake City or Park City, Utah locations. Plus, enjoy free shipping on thousands of products nationwide!

This Item Fits:

• Jeep Wrangler Sport 2018 - 2023
• Jeep Wrangler Unlimited Sport 2018 - 2023
• Jeep Wrangler Unlimited Sport S 2018 - 2023
• Jeep Wrangler Unlimited Rubicon 2018 - 2023
• Jeep Wrangler Rubicon 2018 - 2023
• Jeep Wrangler Unlimited Sahara 2018 - 2023
• Jeep Wrangler Sport S 2018 - 2023
• Jeep Wrangler Unlimited Moab 2018 - 2019
• Jeep Wrangler Rubicon Deluxe 2019 - 2020
• Jeep Wrangler Unlimited Rubicon Deluxe 2020
• Jeep Wrangler Unlimited Rubicon Xtreme 2020
• Jeep Wrangler Unlimited Sport Altitude 2021 - 2023
• Jeep Wrangler Unlimited Willys Sport 2021 - 2023
• Jeep Wrangler Unlimited Sahara Altitude 2021 - 2023
• Jeep Wrangler Unlimited Willys 2021 - 2023
• Jeep Wrangler Willys 2021 - 2023
• Jeep Wrangler Willys Sport 2021 - 2023
• Jeep Wrangler Freedom 2021
• Jeep Wrangler Freedom 2023
• Jeep Wrangler Unlimited Freedom 2021
• Jeep Wrangler Unlimited Freedom 2023
• Jeep Wrangler Unlimited Islander 2021
• Jeep Wrangler Islander 2021
• Jeep Wrangler Unlimited High Altitude 2022 - 2023
